Main Features:
1. Dual outputs, for smart load management
2. Maximum PV input current increases to 27A
3.Wide PV input voltage range 90VDC ~ 450VDC
4.Status indication with RGB lights
5.Built-in Wi-Fi for mobile monitoring (Android/iOS App is available)
6.Supports USB On-the-Go function
7.Reserved communication port for BMS (RS485, CAN-BUS or RS232)
8.Replaceable fan design for ease of maintenance
9.Battery independent design
10.Selectable high power charging current
11.Compatible to Utility Mains or generator input
12.Built-in anti-dust kit
13.Optional DC output for DC fan, LED bulb, router and so on (only for 8K model)
14.Parallel operation with 6 units
Technical Specifications:
| Model | MAX 11000 |
| Rated Power | 11000VA/11000W |
| Parallel Capability | YES,6 units |
| INPUT | |
| Voltage | 230 VAC |
| Select-able Voltage Range | 170-280VAC (For Personal Computers) 90-280VAC (For Home Appliances) |
| Frequency Range | 50 Hz/60 Hz (Auto sensing) |
| OUTPUT | |
| AC Voltage Regulation (Batt. Mode) | 230 VAC ± 5% |
| Surge Power | 22000VA |
| Efficiency (Peak) | 93% |
| Transfer Time | 10 ms (For Personal Computers), 20 ms (For Home Appliances) |
| Waveform | Pure sine wave |
| DC Voltage | N/A |
| BATTERY | |
| Battery Voltage | 48 VDC |
| Floating Charge Voltage | 54 VDC |
| Overcharge Protection | 63 VDC |
| SOLAR CHARGER & AC CHARGER | |
| Solar charger type | MPPT |
| Max PV Array Power | 11000W (5500W x 2) |
| MPP Range @operating Voltage | 90 ~ 450 VDC |
| Max PV Array Open Circuit Voltage | 500 VDC |
| Maximum PV Input Current | 27A x 2(MAX 40A) |
| Max Solar Charge Current | 150A |
| Max AC Charge Current | 150A |
| Max Charge Current | 150A |
| PHYSICAL | |
| Dimension, D x W x H (mm) | 147.4 x 432.5 x 553.6 |
| Net Weight (kgs) | 18.4 |
| Communication Interface | USB/RS232/RS485/WiFi/Dry-contact |
| OPERATING ENVIRONMENT | |
| Humidity | 5% to 95% Relative Humidity(Non-condensing) |
| Operating Temperature | -10°C to 50°C |
| Storage Temperature | -15°C to 60°C |
| STANDARD | |
| Compliance Safety | CE |
