| Product type: TYF-51.2V100Ah-F | |||
| Battery Type | LifePO4 battery | Installation Method | Wall-mounted |
| Voltage | 51.2V | Battery Capacity | 100Ah |
| Charging limit voltage | 58.4V | Discharge limit voltage | 40V |
| Charge current | 50A | Discharge current | 100A |
| Product weight | about 45 Kg | Size | 630(L)*440(W) *150(H) (mm) |
| BMS | Built-in Smart BMS | ||
| Low Temperature Charging Cut-off | |||
| High Temperature Charging or Discharging Cut-off | |||
| Over Charging or Discharging Protection | |||
| Over Current & Short Circuit Protection | |||
| Battery Cells Auto Balance | |||
